Miniature Circuit Breaker Acti9 NG125L 4Poles D-Curve 32A 415V IP20 Schneider Electric

Watch this product and we will notify you once it is back in stock.

The product is now watched
We will notify you once the product is back in stock again.

Miniature Circuit Breaker Acti9 NG125L 4Poles D-Curve 32A 415V IP20 Schneider Electric

This Acti9 NG125L product is a low voltage circuit breaker, It is a 4P circuit breaker with 4 protected poles and 32A In rated current.

Description

 This Acti9 NG125L product is a low voltage circuit breaker. It is a 4P circuit breaker with 4 protected poles and 32A In rated current and D tripping curve. The rated short circuit breaking capacity goes up to 100kA at 220VAC to 240VAC conforming to EN/IEC 60947-2 standard and 100kA at 220VAC to 240VAC conforming to EN/IEC 60947-2 standard. It complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. This miniature circuit breaker protects circuits against short circuit and overload current. It is suitable for isolation in the industrial sector according to IEC/EN 60947-2 standard. The fault tripping is indicated by a red mechanical state indicator light on the front face of the circuit breaker. It has an electrical endurance going up to 10000 cycles and a mechanical endurance going up to 20000 cycles. The Ue operational voltage is going from 380VAC to 415VAC. The Ui rated insulation voltage is 690VAC. The Uimp rated impulse withstand voltage is 8kV. The operating frequency is 50Hz or 60Hz. It is DIN rail mountable. Its width is 12 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -30°C to 70°C. The storage temperature is -40°C to 70°C.

Technical Information

  • Voltage type: AC/DC
  • Built-in depth: 47 mm
  • Rated current: 32 A
  • Rated voltage: 415 V
  • Frequency: 50-60 Hz
  • Release characteristic: D
  • Rated insulation voltage Ui: 690 V
  • Current limiting class: 0
  • Over voltage category: 4
  • Pollution degree: 3
  • Width in number of modular spacings: 6
  • Explosion-proof: No
  • Degree of protection (IP): IP20
  • Number of protected poles: 4
  • Concurrently switching neutral conductor: Yes
  • Connectable conductor cross section solid-core: 1.5-50 mm²
  • Connectable conductor cross section multi-wired: 1-35 mm²
  • Ambient temperature during operating: -30-70 °C
  • Flush-mounted installation: No
  • Additional equipment possible: Yes
  • Number of poles (total): 4
  • Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V: 0 kA
  • Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: 0 kA
  • Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V: 100 kA
  • Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V: 50 kA
  • Rated impulse withstand voltage Uimp: 8 kV

Specifications

  • Measure (WxHxD): 108x103x81mm
